The VPFlowScope® M is a three-in-one flow meter for compressed air and technical gases. It measures flow, pressure and temperature simultaneously. Unlike traditional flow meters, the VPFlowScope M does not require traditional recalibration, where you have to ship the unit back. Instead, the VPFlowScope M consists of a transmitter and the patented VPSensorCartridge® which reduces recalibration to a simple exchange.

Features and benefits:

• Three sensors in one instrument
• For compressed air and technical gases
• Patented VPSensorCartridge®: no more recalibration required
• Ethernet interface: Industry 4.0/IOT ready
• Ultra compact size and low weight
• Ethernet (Modbus/ TCP)
• RS485 (Modbus RTU)
• 4 … 20 mA linearized, pulse mode or alarm output
• USB interface for configuration and downloading of data log files
• Optional TFT color display
• Optional data logger with up to 365 days @ 1 second interval + cyclic recording
• Optional Wi-Fi interface (Web server for configuration, Modbus / TCP)
• Optional: Bi-directional

Applications:

• Compressed air audits
• Nitrogen and technical gas flow measurements
• Cost allocation
• Leak detection
• Pipe network optimization
• Permanent monitoring
